| battery | battery Capacity（Ah） | 50Ah/100Ah/200Ah/300Ah Optional |
| Battery Rack Voltage | 200V to 1000V compitable with inverter voltage | |
| Rack Capacity | 20kwh to 240kwh (volt * Ah) | |
| Paraller Capacity | Rack Capacity x rack numbers | |
| Single Battery Module | 2.6kwh / 5kwh /8kwh/10kwh/24kwh optional | |
| HV DC Unit | Maximum voltage | 1000V |
| Maximum Current | 125A / 250A optional | |
| Protection | Low voltage high voltage over current | |
| Communication | Modbus / CAN optional | |
| Local Display | yes | |
| PCS | PCS Brand | Hopewind/Sinexcel/Sermater |
| Capacity | 30Kw To 500kw | |
| Voltage | Three phase 400V 50Hz or costomized | |
| Costomer supply PCS | yes,need to match BMS protocol | |
| Off-Grid mode | yes,need to set manually | |
| MPPT Controller | Capacity | 20Kw To 75kw |
| Maximum Current | 50A/67A/100A Optional | |
| Rater Voltage | 600VDC | |
| MPPT Voltage Range | 300VDC-820VDC | |
| MPPT Input Numbers | 4/6/8 | |
| EMS | Mode | Peak shifting ， solar self-consumption，off-grid |
| Metering | yes | |
| Communication | Wifi 4G optional | |
| Cloud Based | yes |
FAQ:
Battery Cell
1：What battery cell you are using?
We are using BYD or Gotion brand new prismatic cell. If necessary, please contact us for battery cell specifications.
2：How many cycles can achieve for your battery cells?
BYD and GOTION brand new cells can achieve 6000 cycles @ 25℃, 0.5C conditions. Also please know usually 1C condition is about 3500 cycles.
Low Voltage Battery
1：Which hybrid inverter your battery BMS has been communicated
Our BMS has built protocol communication with most of inverter brands in market. You can please find the brnad information above picture.
High Voltage Battery
1：Which hybrid inverter your high voltage battery BMS has been communicated
Our high voltage battery BMS has built protocol communication with Growatt, Sofarsolar, Goodwe, INVT, Megarevo etc brand three phase hybrid inverters.
2： Why we use high voltage battery?
High voltage battery always works with three phase hybrid inverters, which need a higher battery output. So we need high voltage battery solution to achieve a bigger kW power.
3： How much total voltage I need?
Warranty
1：What's your warranty years?
We offer standard factory warranty which is valid 10 years for battery product, from the date of installation or no more than 10 and a half years from the delivery date from factory. The battery capacity will be no less than 70% within 10 years or 10MWh battery through put per kWh of the initial installation date by conditions charge rate is no more than 0.5C, and environment temperature should be in the range of 0℃ to 30℃.
2：If battery has issues, how you proceed for warranty?
Our engineer will remotely check the issues by software, this need local installer assistance. If it is software issue, the battery can be repaired by firmware update. If it is battery hardware issue, we will send the battery module or BMS to customer as the replacement.
Service
1：Can you offer OEM or ODM?
