OEM 10 kW 10kWh Stacked Energy Storage Batteries

Factory OEM 10kW 10kWh Stacked Solar Energy Battery Pack For 10 Year Warranty








Model Capacity
Ground Eco
5.8kWh
Ground Eco
11.6kWh
Ground Station
17.5kWh
Capacity Energy
5.8kWh
11.6kWh
17.5kWh
Capacity Ah
Capacity Ah
Capacity Ah
Capacity Ah
Suggested SOC
10%-100%
10%-100%
10%-100%
Usable Capacity
5.3kWh
10.4kWh
15.7kWh
Nominal Voltage
51.2V
51.2V
51.2V
Operation Voltage
46.4V – 57.6V
46.4V – 57.6V
46.4V – 57.6V
Maximum Charging/Discharging Current
70A/70A
100A/100A
100A/100A
BMS
Robust Multi point monitoring BMS pre installed
Life Cycling (0.5C 25℃)
Life Cycling (0.5C 25℃)
Warranty BTT
10MWh per kWh
5 years, whichever comes sooner
Operation Temperature
0℃ ~ 45℃
Storage Temperature
-20℃ ~ 35℃
Weight
28kG per pack
28kG per pack
72kG per pack
Dimensions
420x420x 600 mm
420x420x 920 mm
620x420x600 mm
Scalable
Yes, maximum 15 packs can be parallel connected
Certifications
MSDS, UN38.3, RoHS, IEC62619, UL
Communication
RS485
Accessories
One pair short parallel power cables and comm cable as the standard accessories
Botton bearing plate and 2 meter length inverter canbles need to be brought


FAQ:

Battery Cell

1:What battery cell you are using?

We are using BYD or Gotion brand new prismatic cell. If necessary, please contact us for battery cell specifications.

2:How many cycles can achieve for your battery cells?

BYD and GOTION brand new cells can achieve 6000 cycles @ 25℃, 0.5C conditions. Also please know usually 1C condition is about 3500 cycles.


Low Voltage Battery

        1:Which hybrid inverter your battery BMS has been communicated

Our BMS has built protocol communication with most of inverter brands in market. You can please find the brnad information above picture.


High Voltage Battery

        1:Which hybrid inverter your high voltage battery BMS has been communicated

Our high voltage battery BMS has built protocol communication with Growatt, Sofarsolar, Goodwe, INVT, Megarevo etc brand three phase hybrid inverters.

        2: Why we use high voltage battery?

High voltage battery always works with three phase hybrid inverters, which need a higher battery output. So we need high voltage battery solution to achieve a bigger kW power.

        3: How much total voltage I need?

This depends on inverter battery side specifications. For three hybrid inverter, it is always around 150V to 600V. We just need to consider this HV battery system volatge is in this range.


Warranty

        1:What's your warranty years?

We offer standard factory warranty which is valid 10 years for battery product, from the date of installation or no more than 10 and a half years from the delivery date from factory. The battery capacity will be no less than 70% within 10 years or 10MWh battery through put per kWh of the initial installation date by conditions charge rate is no more than 0.5C, and environment temperature should be in the range of 0℃ to 30℃.

        2:If battery has issues, how you proceed for warranty?

Our engineer will remotely check the issues by software, this need local installer assistance. If it is software issue, the battery can be repaired by firmware update. If it is battery hardware issue, we will send the battery module or BMS to customer as the replacement.

Service

        1:Can you offer OEM or ODM?

Yes, we are LFP battery specialized solution provider mianly in energy storage field. You can please inform us your applications, inverter brand and model name. We will select or customize LFP battery system for you.
